RL-5472 Through Hole Power Inductor
The RL-5472 Through Hole Power Inductor series is designed for high-efficiency performance in switching regulated power supply applications. Built with high-saturation ferrite cores, these inductors offer low core losses and stable operation across a wide current range. Their compact through-hole design supports easy integration into equipment layouts, providing a reliable solution for demanding electronics. Optimized for both durability and electrical performance, the RL-5472 series is an excellent choice for power conversion and filtering circuits.
- High-saturation ferrite core material for efficient magnetic performance
- Through-hole construction for secure mechanical stability
- Compact form factor to optimize PCB space usage
- Designed for low core loss operation under demanding loads
- Reliable thermal stability over wide operating temperatures
- Optimized for use in regulated power supply designs
- Inductance Range: 21 μH to 400 μH
- Saturation Current: 0.7 A to 5.0 A
- Storage Temperature Range: -55°C to +130°C
- Operating Temperature Range: -40°C to +130°C
- Minimum Body Diameter: 25.40 mm (1.000 in)
- Maximum Body Length: 25.15 mm (0.990 in)
- Lead Diameter: 0.81 mm (0.032 in)
- Maximum Height: 14.48 mm (0.570 in)
- Weight: 13.0 g (0.44 oz)
The RL-5472 inductor series is designed for use in switching regulators, boost converters, and buck/buck-boost circuits. It is well-suited for regulated DC-DC power supplies, energy storage systems, and filtering applications in industrial and consumer electronics.
