RL-3901 Through Hole Power Inductor
The RL-3901 Through Hole Power Inductor series is designed for compact, efficient performance in power supply applications. Its high-saturation core material allows the inductor to maintain stable inductance under heavy load conditions, providing dependable operation in regulated switching circuits. The compact axial design supports space-conscious PCB layouts while enabling straightforward installation. Built for durability and consistent performance, this series is ideal for demanding electronics applications.
- Axial leaded construction for streamlined mounting
- Compact size supports high-density PCB layouts
- Durable core design for extended operational life
- Reliable operation in demanding electrical environments
- Precision construction for consistent electrical characteristics
- Designed for integration into regulated switching circuits
- Inductance Range: 100 µH to 680 µH
- Saturation Current: 0.70 A to 2.79 A
- Storage Temperature Range: -55°C to +130°C
- Operating Temperature Range: -40°C to +130°C
- Maximum Body Diameter: 0.25 in (6.35 mm)
- Lead Length: 1.00 in (25.40 mm) minimum
- Body Length: 0.65 in (16.51 mm) maximum
- Part Weight: 1.7 g (0.06 oz)
The RL-3901 inductor series is well-suited for switching regulated power supplies, powerline filtering, and small form-factor circuit designs. Its high-saturation material ensures stable inductance in demanding operating conditions. With its compact axial construction, it is also ideal for equipment where space and reliability are critical.
