RL-1960 Through Hole Power Inductor
The RL-1960 Through Hole Power Inductor series is designed to deliver high current handling and consistent inductance across a broad range of operating conditions. Its compact cylindrical form factor and axial leads make it ideal for space-conscious PCB layouts while supporting high-performance power regulation. With enhanced thermal stability and robust mechanical construction, this inductor provides long-term reliability in demanding electrical environments. The RL-1960 is specifically tailored for use in switching power supplies and applications requiring tight inductance control and low magnetic interference.
- High flux density core material
- Axial leaded design for secure PCB mounting
- Wide inductance range available
- Handles high DC saturation currents
- Compact form factor
- Excellent thermal stability
- Reliable mechanical structure
- RoHS compliant construction
- Storage Temperature Range: -55°C to +130°C
- Operating Temperature Range: -40°C to +130°C
- Inductance Range: 47 µH to 2200 µH
- DC Saturation Current: up to 20 A
- Mounting Type: Through Hole
- Configuration: Axial Leaded
- Construction: Shielded core with 4-40 clearance mounting hole
The RL-1960 inductor series is ideally suited for switching power supply circuits, where high current and compact form factor are essential. These inductors are frequently used in regulated DC-DC converters, current choke circuits, and voltage smoothing applications across telecommunications, industrial electronics, and embedded systems. Their high saturation current and thermal resilience make them dependable components in high-efficiency power management designs.
